Product Description
A compact, IP65-rated moving head beam fixture delivering sharp, multi-color beams and stunning aerial effects through continuous 360-degree rotation, a powerful LED engine, dual prisms, and aperture gobos. Perfect for touring, festivals, and permanent installations where a compact, powerful, and weather-resistant beam fixture is needed for dynamic effects in any environment.
SPECIFICATIONS
-
Light Source: 1 LEDs (Red,Mint,Blue) 120 W, (3.34A), 50,000 hours life expectancy
-
Color Temperature (at full): 10,398 K
-
Front lens diameter: 140 mm
-
CRI: 80.8
-
Beam Angle: 1.9°
-
Field Angle: 2.7°
-
Cutoff Angle: 3.4°
-
Lumens (Output): 4,488
-
Illuminance (total): 117,690 lux @ 5 m
-
Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 15000 Hz
- Pan and Tilt: 360°/360° total movementPan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
- Gobos (1): 17 + open (metal), continuous scroll at variable speeds
- Gobo Size: Gobo Wheel (rotating): 6 mm (outside), .6 mm (max. thickness)
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Focus: Motorized
- Frost: Motorized
- Prism: 6 Facets, motorized, linear, rotating
- Prism: 8 Facets, motorized, round, rotating
- Strobe Rate: 0 to 30 Hz
- Dim Curves: 4
- Control Protocol: DMX, RDM
- DMX Channels: 21 or 25
- Modes/Personalities: 2 personalities (21, 25)
