Product Description
A versatile, IP65-rated RGBwWL LED batten that delivers a full spectrum of color and high-quality whites from 24 homogenized cells, providing seamless pixel-mapping effects and powerful washes. Ideal for touring, festivals, broadcast, and theatrical applications, its silent, all-weather, and camera-ready performance excels in both temporary and permanent installations.
SPECIFICATIONS
- Light Source: 24 (RGBWwL) LED Engines
- Color Temperature (range): 2800 to 8000 K
- Color Temperature (at full): 9167 K
- CRI: 95
- Beam Angle: 16.7°
- Beam Angle (w/CYC Diffusion): 40.7°
- Beam Angle (w/Half Diffusion): 18.9°
- Beam Angle (w/Stealth Diffusion): 25°
- Field Angle: 36.1°
- Field Angle (w/CYC Diffusion): 84.4°
- Field Angle (w/Half Diffusion): 46.8°
- Field Angle (w/Stealth Diffusion): 61.2°
- Lumens: 25,198
- Lumens (w/CYC Diffusion): 32,913
- Lumens (w/Half Diffusion): 23,920
- Lumens (w/Stealth Diffusion): 8,571
- Illuminance: 5,834 lux @ 5 m
- Illuminance (w/CYC Diffusion): 1,739 lux @ 5 m
- Iluminance (w/Half Diffusion): 3,788 lux @ 5 m
- Iluminance (w/Stealth Diffusion): 932 lux @ 5 m
- Selectable PWM: 1,000 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 12,000 Hz, 25,000 Hz
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Strobe Rate: 0 to 30 Hz
- Color Temperature Presets: Yes
- Dim Modes: 4
- Dim Curves: 4
- Built-in Automated Programs: Yes
- Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
- Power Input: Seetronic Powerkon IP65
- Power Output: Seetronic Powerkon IP65
- Data Connectors: 5-pin IP65 XLR, Seetronic etherCON® compatible
- Software Connection: USB
- Control Protocol: Art-Net, sACN, DMX, CRMX, RDM
- Modes/Personalities: 72 personalities
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 0 units @ 100 V; 2 units @ 120 V; 4 units @ 208 V; 4 units @ 230 V, 4 units @ 240 V
- Power and Current: 610 W, 6.10 A @ 100 V, 60 Hz [10 A inrush]
- Power and Current: 600 W, 4.98 A @ 120 V, 60 Hz [12 A inrush]
- Power and Current: 590 W, 2.78 A @ 208 V, 60 Hz [17 A inrush]
- Power and Current: 575 W, 2.55 A @ 230 V, 50 Hz [34 A inrush]
- Power and Current: 573 W, 2.50 A @ 240 V, 60 Hz [27 A inrush]
