Product Description
A high-output fog machine that illuminates powerful bursts of fog with advanced RGBA+UV LED color mixing, creating ferocious atmospheric effects. Ideal for concerts, theatrical productions, and special events requiring powerful, colored fog effects that can be deployed vertically, horizontally, or from overhead trusses.
SPECIFICATIONS
- Light Source: 10 LEDs (RGBA/UV) 8.5 W, (3 A), 50,000 hours life expectancy
- PWM Frequency: 126 Hz
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Strobe Rate: 0 to 20 Hz
- Output: 40,000 cfm
- Low Fluid Shutdown: No
- Tank Capacity: 0.7 gal (2.5 l)
- Fluid Consumption: 80 ml/min
- Maximum Run time: 1 hour @ 40s bursts, 1m intervals (using Chauvet QDF fluid)
- Maximum Run time: 2 hours @ 40s bursts, 2m intervals (using Chauvet QDF fluid)
- Maximum Run time: 2.5 hours @ 40s bursts, 3m intervals (using Chauvet QDF fluid)
- Power Connection: Edison plug to Seetronic Powerkon IP65
- Power Input: Seetronic Powerkon IP65
- Data Connectors: 3- and 5-pin XLR
- Cable Length (power): 5 ft (1.5 m)
- Control Protocol: DMX
- DMX Channels: 15
- Modes/Personalities: 1 personalities
- On-Board Control: Yes
- Included Remote: No
-
Input Voltage (120V): 120 VAC, 60 Hz
- Input Voltage (220V): 230 VAC, 50 Hz
-
Power and Current (120V): 1,480 W, 12.55 A @ 120 V, 60 Hz
- Power and Current (220V): 2,880 W, 12.55 A @ 230V, 60 Hz
- Heat-up Time (120V): 10 min
-
-
Breaker Size (120V): 15A
- Breaker Size (220V): 15A
