Product Description
Features
Fully featured, compact and lightweight IP65 1,250 W LED yoke profile fixture including CMY + CTO color mixing, a 4-blade framing shutter system with rotation, a color wheel, 10:1 zoom, 2 prisms (5 facet round and linear, 2 rotating gobo wheels, integrated sun shield
AT A GLANCE
- Fully featured, compact and lightweight IP65 1,250 W LED yoke profile fixture including CMY + CTO color mixing, a 4-blade framing shutter system with rotation, a color wheel, 10:1 zoom, 2 prisms (5 facet round and linear, 2 rotating gobo wheels, integrated sun shield
- 16-bit dimming of master dimmer for smooth control of fades
- Variable CMY + CTO color mixing system to create a wide pallet of colors
- CRI and CTB filters on color wheel for added flexibility
- Two rotating, indexing and interchangeable slot and lock gobo wheels
- An animation wheel for kinetic textured effects
- DMX , WDMX, sACN, and Art-Net for full flexibility of control options
- RDM control over DMX for fixture reporting
- 5.6° to 56.8° zoom range for variable beam sizes
- Iris, 5-facet round and linear prisms, and 2 frosts (light and medium) for beam control
- True 1 compatible power input
- Integrated sun shield for protecting the optical path from sunlight when the fixture is off
- Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup
- USB slot for software uploads
- Battery backup display with auto-rotate depending on fixture orientation
Warranty
2 year warrantyProduct Videos
Custom Field
varPOA 1
varSpecTab 1
Fixture Type Profile
varSectionName Optical
Light Source LEDs (CW) 1,250 W, (4 A), 7500 K, 50,000 hours life expectancy
Color Temperature 6813 K (at full)
CRI 69.9
CRI with CRI Filter 88.3
Front Lens Diameter 188 mm
Beam Angle 5.6° to 48°
Field Angle 6.6° to 54.4°
Cutoff Angle 7.1° to 56.8°
Zoom Range 5.6° to 56.8°
Lumens – Source 94,000
Lumens – Output 59,168
Illuminance (5.6°) 134,034 lux @ 5 m
Illuminance (54.4°) 4,241 lux @ 5 m
Selectable PWM 600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
varSectionName Dynamic Effects
Pan 540°
Tilt 270°
Pan and Tilt Ranges 540°, 360°, 180° pan/270°, 180°, 90° tilt
Colors 6 (including CRI and CTB fi lters) + white, split colors, continuous scroll at variable speeds
Colors CMY flags, CTO flag
Gobos (1) 6 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobos (2) 6 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobo Size: Gobo Wheel 1 30 mm (outside), 25 mm (image), 1.1 mm (max. thickness)
Gobo Size: Gobo Wheel 2 30 mm (outside), 25 mm (image), 1.1 mm (max. thickness)
Framing Shutters 4 blades, each with dual axis movement.
Framing Shutter rotation +/- 60° rotation.
Dimmer Electronic
Dim Curves 4
Shutter/Strobe Electronic
Strobe Rate 0 to 20 Hz
Zoom Motorized
Focus Motorized
Frost Motorized
Iris Motorized
Prism 1 5 Linear Facets, motorized, rotating
Prism 2 5 Circular Facets, motorized, rotating
Move-in-Black Yes
varSectionName Construction / Physical
Dimensions 18.3 x 11.93 x 32.91 in (465 x 303 x 836 mm)
Weight 102.5 lb (46.5kg)
Housing Material Aluminum diecast, High-impact flameretardant polymer, Steel
varSectionName Connections
Power Input/Output Seetronic Powerkon IP65
Data Connectors 5-pin IP rated XLR, Neutrik IP rated RJ45 Connectors in/out
varSectionName Control
Control Protocol Art-Net, DMX, RDM, W-DMX, sACN
DMX Channels 38 or 55
Art-Net Channels 38 or 55
Modes/Personalities 2 personalities (38, 55)
varSectionName Electrical
Input Voltage 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current 1780 W, 15.07 A @ 120 V, 60 Hz
varSectionName What's Included
Maverick Storm 4 Profile 1
Seetronic Powerkon IP65 power cord to Bare End 5 ft (1.5 m)
Omega bracket with mounting hardware 1
Warranty Card 1
Quick Reference Guide or User Manual 1
