Product Description
Features
The COLORband Q4 IP is a weatherproof, outdoor-rated LED strip light delivering lighting joy inside or out because its robust housing repels water, snow, dirt, and sand for all-weather applications. COLORband Q4 IP is a versatile 4-zone effect that can be used for a wide variety of applications including as a blinder or wall washer. The touch-sensitive display can be password protected and powerCON® TRUE1 inputs make power connections secure and reduce cable clutter by linking multiple units. The integrated GORE® valve prevents internal humidity build-up and allows the fixture to breathe. COLORband Q4 IP is even great for on-camera work with its high-frequency LED dimming that gives the unit flicker-free video operation.
Highlights
- Robust housing repels water, snow, dirt and sand for all-weather applications
- Prevent internal humidity build-up and allow the fixture to breathe with the integrated GORE® valve
- Achieve flicker-free video operation with high-frequency LED dimming
- Reduce the need for extra extension cords with power and data linking outputs
Warranty
2 year limited warrantyProduct Videos
Custom Field
Fixture Type Strip
varSpecTab 1
varSectionName Specifications
DMX Channels 4, 7, 10, 16 or 22
DMX Connectors 3-pin XLR
Light Source 12 LEDs (quad-color RGBA) 6 W, (2.06 A), 50,000 hours life expectancy
Strobe Rate 0 to 20 Hz
PWM Frequency 4 KHz
Beam Angle 14°
Field Angle 27°
Illuminance 7,074 lux @ 2 m, 1,209 lux @ 5 m
Lumens 2,923
IP Rating IP65
Power Linking 9 units @ 120 V
Input Voltage 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current 87 W, 1.18 A @ 120 V, 60 Hz
Weight 11.8 lb (5.35 kg)
Size 39.3 x 3.2 x 4.1 in (998 x 81 x 104 mm)
Approvals CE, MET
Power Cord Length 5 ft (1.5 m)
varSectionName What's Included
Power Cord 1
DMX (in) adaptor 1
DMX (out) adaptor 1
Quick Reference Guide 1
Warranty card 1
