PRESIDOR Wall Stations

Write a Review
P.O.A.
P.O.A. stands for 'Priced on Application' and typically means we need to contact the factory to get a quote specifically for your venue/company. Please click Add to Quote and we'll get a quote to you as soon as possible.

SKU:
JSI-PWS
MPN:
PWS

Presidor™ Wall Stations (PWS) represent the next step in Architainment Lighting Controls. Intuitive operation is coupled with state-of-the-art capacitive touch technology permitting powerful distributed lighting controls for single or multi-room environments. Attractive 1 gang "Patent Pending" design is supported by color-matched adapter plates up to 7 gang and surface mount back boxes. Supporting up to 70 presets on a single universe of DMX512, a PWS can operate as either a DMX console or a DMX snapshot/playback device. Flexible and programmable auxiliary contact input, RS232 input and real-time scheduling allow for a myriad of interface possibilities with Building Management and Show Control systems. Wiring topology is fast, simple and inexpensive with standard Cat5/5e or Cat6 cabling using standard RJ-45 connectors or existing Belden #9773 wiring using standard Phoenix style connectors. Daisy-chain up to 15 stations per room for multi-room environments for up to 25 rooms when using one or more Presidor™ Room Linker/Combiner (PRLC).

Typical applications are wide ranging from theatre house lights, moving lights, LED fixtures, churches, corporate boardrooms, hotel ballrooms, convention facilities, museums, art galleries and other DMX512 or RS232 controlled devices.




Theatrical

PWS-70P-DMX-B


Architectural

PWS-70P-DMX-W



  • Attractive "Patent Pending" screwless design is ergonomic and sealed to dust.
  • 70 presets on one universe of 512DMX channels.
  • Operates as either a DMX console or a DMX snapshot/playback device.
  • State-of-the-art high speed, low power "green" processor and ancillary circuitry with a power consumption < 1/4 Watt.
  • RS232 Input.
  • Bluetooth ready for remote preset activation via cell phone.
  • Dual integrated light pipes allow for both automatic proximity sense and ambient light sense.
  • Embedded programming with alphanumeric preset labeling.
  • Intuitive navigation allows ease of operation.



  • Unique interactive real-time functionality including manually activated digital sliders.
  • Password-protected access for customized security.
  • Up to 15 daisy-chained stations per room/zone power and data inclusive over Cat5/5e/6 or 3-Pair cable.
  • Up to 25 rooms/zones per DMX universe with the use of Presidor™ Room Linker/Combiner (PRLC).
  • Small compact size permits installation in standard, readily available single gang electrical back boxes.
  • Available in white or black with optional color-matched adapter plates and surface mount back boxes allow for virtually unlimited retrofit possibilities.
  • Patent Pending.
